RAHMEN
RAHMEN
Aluminium Lite, AMF, Double Butted, Internal Cable Routing, Tapered Head Tube, Flat Mount Brake, SIC Mount, FM Kickstand Mount
GRÖSS
Size Split: 27.5: XS (14″), S (16″) // 29: M (18″), L (20″)
FAHRWERK
FEDERGABEL
SR Suntour XCT Disc, 100mm
ANTRIEB&BREMSE
BREMSANLAGE
Tektro HD-M275 / TKD-150, Hydr. Disc Brake (160/160)
SCHALTWERK
Shimano RD-M360, 8-Speed
UMWERFER
Shimano FD-M315, Top Swing, 31.8mm Clamp
SCHALTHEBEL
Shimano SL-M315, Rapidfire-Plus
INNENLAGER
Feimin FP-B902N, 73mm BSA
KURBELGARNITUR
Shimano FC-M315, 36x22T, 170mm
KASSETTE
Shimano CS-HG31, 11-34T
KETTE
KMC Z8.3
COCKPIT
LENKER
CUBE Rise Trail Bar, 680mm
VORBAU
CUBE Performance Stem, 31.8mm
GRIFFE
ACID React
STEUERSATZ
CUBE FPH868, Semi-Integrated
LAUFRÄDER
VORDERRAD NABE
CUBE Alloy Light, QR, 6-Bolt
HINTERRAD NABE
CUBE Alloy Light, QR, 6-Bolt
FELGEN
CUBE ZX20, 32H, Disc
REIFEN
CUBE IMPAC Smartpac, 2.25
AUSSTATTUNG
SATTELSTÜTZE
CUBE Performance Post, 27.2mm
SATTEL
Natural Fit Venec Lite WS
PEDALE
CUBE PP MTB
ARTIKELINFORMATIONEN
GEWICHT
14,8 kg
