RAHMEN
RAHMEN
Aluminium Lite, AMF, Double Butted, Internal Cable Routing, Tapered Head Tube, Flat Mount Brake, SIC Mount, FM Kickstand Mount
GRÖSS
Size Split: 27.5: XS (14″), S (16″) // 29: M (18″), L (20″)
FAHRWERK
FEDERGABEL
SR Suntour XCM Disc, 100mm, Remote Lockout
ANTRIEB&BREMSE
BREMSANLAGE
Shimano BR-MT200/UR300, Hydr, Disc Brake, PM/FM (160/160)
SCHALTWERK
Shimano RD-M3100-SGS, 9-Speed
UMWERFER
Shimano FD-M2020, Top Swing, 31.8mm Clamp
SCHALTHEBEL
Shimano SL-M2010-9R, Rapidfire-Plus
INNENLAGER
Thun Paso-ML, 73mm BSA
KURBELGARNITUR
Shimano FC-MT101, 36x22T
KASSETTE
Shimano CS-HG201, 11-36T
KETTE
KMC X9
COCKPIT
LENKER
CUBE Rise Trail Bar, 680mm
VORBAU
CUBE Performance Stem Race, 31.8mm
GRIFFE
ACID React
STEUERSATZ
CUBE FPH868, Semi-Integrated
LAUFRÄDER
VORDERRAD NABE
Shimano HB-TX505, QR, Centerlock
HINTERRAD NABE
Shimano FH-TX505, QR, Centerlock
FELGEN
CUBE ZX20, 32H, Disc
REIFEN
Schwalbe Smart Sam, Active, 2.25
AUSSTATTUNG
SATTELSTÜTZE
CUBE Performance Post, 27.2mm
SATTEL
Natural Fit Venec Lite WS
PEDALE
ACID PP MTB
ARTIKELINFORMATIONEN
GEWICHT
14,3 kg
