RAHMEN
RAHMEN
Aluminium Superlite, Gravity Casting, Agile Ride Geometry, 1.5 Headtube, Boost 148, Full Integrated Battery, Advanced Internal Cable Routing, Kickstand/Fender/Carrier Mounting Points
GRÖSS
Size Split: 27.5: S (15″) // 29″: M (17″), L (19″), XL (21″), XXL (23″); Easy Entry: 27.5: S (16″), M (18″), L (20″), XL (22″)
FAHRWERK
FEDERGABEL
X-Fusion MIG32 Air, Tapered, 15x110mm, 120mm, Lockout (EE: 100mm)
E-BIKE SYSTEM
MOTOR
Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System
AKKU
Bosch PowerTube 625
REMOTE
Bosch LED Remote
LADEGERÄT
Bosch 4A
ANTRIEB&BREMSE
BREMSANLAGE
Shimano BR-MT200, Hydr. Disc Brake (180/180)
SCHALTWERK
Shimano Deore RD-M5100-SGS, 11-Speed
SCHALTHEBEL
Shimano Deore SL-M5100-IR, Direct Attach, Rapidfire-Plus
KURBELGARNITUR
ACID E-Crank, 38T, 175mm
KASSETTE
Shimano Deore CS-M5100, 11-51T
KETTE
KMC X11
COCKPIT
LENKER
CUBE Rise Trail Bar Pro, 740mm
VORBAU
CUBE Performance Stem E-MTB, 31.8mm
GRIFFE
ACID React Pro / EE: ACID Hybrid Perform
STEUERSATZ
ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120°, Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm)
LAUFRÄDER
VORDERRAD NABE
Shimano HB-MT400-B, 15mm, Boost, Centerlock
HINTERRAD NABE
Shimano FH-MT400-B, 12mm, Boost, Centerlock
FELGEN
Rodi Tryp 30, 32H, Disc, Tubeless Ready
REIFEN
Schwalbe Smart Sam, Active, 2.6
AUSSTATTUNG
SATTELSTÜTZE
CUBE Performance Post, 30.9mm
SATTEL
Natural Fit Sequence
PEDALE
ACID PP MTB
ARTIKELINFORMATIONEN
GEWICHT
23,8 kg
