RAHMEN
RAHMEN
Aluminum Superlite, Gravity Casting Technology, Efficient Comfort Control, FSP 4-Link, Agile Comfort Geometry, Boost 148, Full Integrated Battery, Advanced Internal Cable Routing
GRÖSS
Size Split: 27.5: S (16″) // 29: M (18″), L (20″), XL (22″)
FAHRWERK
FEDERGABEL
Fox 34 Float AWL, 2-Position Sweep-Adjust RAIL Damper, Tapered, 15x110mm, E-Bike Optimized, 120mm
DÄMPFER
Fox Float DPS EVOL, 185x55mm (27.5: 165x45mm), Open/Medium/Firm Mode, Trunnion Mount
DÄMPFER HARDWARE
Top: 54mm Trunnion Mount, Bottom: 30x8mm
E-BIKE SYSTEM
MOTOR
Bosch Drive Unit Performance CX Generation 4 (85Nm) Cruise (250Watt), Smart System
AKKU
Bosch PowerTube 750
REMOTE
Bosch LED Remote
DISPLAY
Bosch Intuvia 100
LADEGERÄT
Bosch 4A
ANTRIEB&BREMSE
BREMSANLAGE
Magura MT Thirty, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203)
SCHALTWERK
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
SCHALTHEBEL
Shimano Deore SL-M6100, Rapidfire-Plus
KURBELGARNITUR
ACID E-Crank, 38T, 170mm
KASSETTE
Shimano Deore CS-M6100, 10-51T
KETTE
Shimano CN-M6100
COCKPIT
LENKER
Newmen Evolution SL 318.25, 760mm
VORBAU
CUBE Performance Stem E-MTB, 31.8mm
GRIFFE
ACID Hybrid Perform
STEUERSATZ
ACROS AZF-1035, ICR (Integrated Cable Routing), BlockLock 120°, Top Zero-Stack 1 1/2″ (ZS 56mm), Bottom Zero-Stack 1 1/2″ (ZS 56mm)
LAUFRÄDER
VORDERRAD NABE
Shimano HB-MT400-B, 15mm, Boost, Centerlock
HINTERRAD NABE
Shimano FH-MT410-B, 12mm, Boost, Centerlock
FELGEN
CUBE EX30, 32H, Disc, Tubeless Ready
REIFEN
Schwalbe Smart Sam, Active, 2.6
AUSSTATTUNG
SATTELSTÜTZE
CUBE Performance Post, 30.9mm
SATTEL
Natural Fit Sequence
PEDALE
ACID PP MTB
SCHEINWERFER
ACID Front Light PRO-E 110, 5-16V, DC
RÜCKLICHT
ACID Mudguard Rear Light PRO-E, 12V, DC
STÄNDER
ACID FM Pure Kickstand
SCHUTZBLECHE
ACID 75
GLOCKE
Knog Oi
GEPÄCKTRÄGER
ACID Semi-Integrated Carrier, ACID RILink Adapter Compatible
ARTIKELINFORMATIONEN
GEWICHT
27,4 kg
